Front Service Aluminum LED Display

TF Series

TF4, TF5, TF6, TF8, TF10, TF16, TF20

Transparent LED Film Screen, also called adhesive transparent led display, is a newly developed creative and innovative transparent led wall for commercial display applications. The whole design is flexible, soft and curved PCB and panel. It has broken the normal and rigid PCB limits. Transparent led film is adhesive on the glass directly with only 3mm thickness. It creates best visual quality and vivid performance.

Features Specifications FAQs Product Documents

Features

	01. Up to 95% Transparency The base material is high-temperature resistant PET film. The transparent led film screen is almost invisible and completely integrated into the glass when it stops working
02. Customized & Versatile The modular design of the film enables custom shapes and sizes, opening up a world of possibilities for unique installations across various indutries, from retail to hospitality and events
	03. Seamless Integration No visible structural skeleton or keel on the back of transparent led screen, real and completely transparent.
04. Most Flexibility Transparent led film can be bent or cut. It's the best solution for curved or special-shape glass wall.
	05. Superior Scalability It can be customized, combined and spliced according to the demand, which has very great flexibility in display effect.
06. High Resolution Visuals Despite its transparency, the film delivers stunning, high-resolution visuals that captivate audiences, creating unforgettable experiences for customers
	07. Up to 4000nits High Brightness Transparent led film has 1000nits minimum and 4000nits maximum brightness, which is adequate for 95% indoor and outdoor applications. It makes excellent visual performance and vibrant colors.
08. Self-Adhesive & Easy Installation The transparent led film display is extremely light and slim with 3kg/㎡ and 3mm thickness. It's also self-adhesive which makes easy installation.

Specifications

Model	P4.44	P5.71	P6.67	P8	P10
Pixel Pitch	4.44mm	5.71mm	6.67mm	8mm	10mm
LED Type	SMD1415	SMD2727	SMD2727	SMD3535	SMD3535
Pixel Type	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Module Size	480×320mm	480×320mm	480×320mm	480×320mm	480×320mm
Module Resolution	108×72 Pixel	84×56 Pixel	72×48 Pixel	60×40 Pixel	48×32 Pixel
Pixel Density	50,625	30,625	22,500	15,625	10,000
Scan	1/9 Scan	1/7 Scan	1/6 Scan	1/5 Scan	1/2 Scan
Brightness	≥5000nits	≥6000nits	≥6000nits	≥6000nits	≥6500nits
View Angle	140° (H)/140°(V)	140° (H)/140°(V)	140° (H)/140°(V)	140° (H)/140°(V)	140° (H)/140°(V)
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz
Input Voltage	AC100-240V	AC100-240V	AC100-240V	AC100-240V	AC100-240V
Grey Level	14 Bit	14 Bit	14 Bit	14 Bit	14 Bit
MTBF	≥ 10,000 hs	≥ 10,000 hs	≥ 10,000 hs	≥ 10,000 hs	≥ 10,000 hs
Operating Temperature	-30 ℃ ~ +70 ℃	-30 ℃ ~ +70 ℃	-30 ℃ ~ +70 ℃	-30 ℃ ~ +70 ℃	-30 ℃ ~ +70 ℃
Operationg humidity	10%～75%	10%～75%	10%～75%	10%～75%	10%～75%
IP Grade	IP65	IP65	IP65	IP65	IP65
